$15000
We are factory of some kinds of semi trailer, like side wall semi trailer, fence semi trailer, trailer for transport cattle, stake semi trailer, drop side semi trailers, side trailer, fence trailer, trailer for cattle, utility trailer siding, cargo semi trailer.
Product Parameters:
Color : optional
Dimension : 13000mm*2500mm*2000mm
Side wall height : 1600mm. the side wall height is 1000mm and the side flowers bar is 600mm
Loading Capacity (T) : 40-80tons
Axle : 3/4/5axles, fuwa/huajing/bpw brand
Suspension : American Mechanical/Air suspension
King pin : 2.0/3.5, Jost brand
Tare Weight
About 8 T
Dimension
13000mm*2500mm*2000mm
Side wall height
1600mm. the side wall height is 1000mm and the side flowers bar is 600mm
Loading Capacity (T)
40 T
Axle
3axles, 13T, huajing Brand
Rim
9.0-22.5 13pieces
Tire
12.00R22.5 Triangle Brand, 13pieces
Suspension
American Mechanical suspension
Spring leaf
90(W)mm*13(Thickness)mm*10Layer suspension
King pin
JOST brand 3.5 inch bolts type
Support leg
JOST C200T
Main beam
Height: 500mm, upper plate is 14mm, middle plate is 8mm, Down plate is 16mm; Material is Q345B Steel.
Side beam
16mm channel steel (Material is Q235 steel).
Platform
3mm diamond platform
Brake chamber
WABCO RE 6 relay valve; T30+T30 Spring brake chamber, TWO piece of 45L air tanks
ABS
Without
Valve
WABCO valve
Light
LED light
Voltage
24V
Receptacle
7 ways (7 wire harness)
Tool box
One piece, 1m×0.5m×0.5m (Size can be choose freely)(equipped with 1 unit Tire spanner,1 unit gudgeon sleeve and 1 unit cranking bar)
Painting
Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint
Shipping Terms:
By bulk cargo carrier
Payment method
30% of Total value as deposit by T/T after contract signed, rest balanced by T/T before shipment.
