Overall Dimension（mm）

11500x2500x3900mm

Wheelbase

7,500mm+1,310mm+1,310mm

Payload

42,000kg

Tare weight

10,000kg

G.V.W.R.

52,000kg

Function

transport Fuel, Oil, Diesel

Volume

42000L

Thickness(mm)

Material Q235 carbon steel

Tank body 5mm   Dish end plate:  6mm

Welding standard

All welding are to be done by qualified welder per applicable national standard

Compartment

3 compartments ( 3*14000L )

Manhole cover

3 units Safety manhole with breath valve, Aluminum, diameter 500mm.

Discharge valve

3units  3” API valve with dust cover, aluminum Henghe Brand

Bottom valve

3 units 4 inch Pneumatic aluminum valve, 1pcs, Henghe Brand

Discharge pipe

3〞seamless steel tube, 6m

Tanker body test

Hydrostatic test to 5 psi (35 Kpa) on each compartment

Axle

13Ton, ZY brand optional FUWA brand

Tire

12R22.5, 12 pcs.

Suspension system

Mechanical Suspension

Steel Spring

10/10/10 leaf spring with 90mm(W) *13mm(thickness)

Brake air chamber

6 units T30/30 spring brake chambers

Emergency relay valve

Wabco relay valve

Traction/King Pin

2” and 3.5” removable Kingpin, bolted in type 500mm from the front face of the front bolster

Landing Gear

Standard 28ton external two speed telescopic manual operation

Tool box

1pcs, One crank and one shaft head wrench

Fire extinguisher

2 units per trailer

Handrail

800mm height, pneumatic controlling

Walkway

Anti-skid walk way from rear to first manhole

Ladder

High folding ladder

Spare wheel carriers

2 pcs

Paint

Shot blast at Standard SA 2.5 prior to application of primer, polyurethane top coat. Total DFT not less than 100um,A layer of anti-rust paint,two-layer finish.Waxed

Packing

Nude, Polish with wax before shipping
